VSV-01/0.005-0.048ml-SSH-101D-000
Price on request
Article number:
1043410
Available downloads for "VSV-01/0.005-0.048ml-SSH-101D-000"
Login
Product information "VSV-01/0.005-0.048ml-SSH-101D-000"
| Chem. resistance of metals: | No specific resistance |
|---|---|
| Chem. resistance of nonmetals: | No specific resistance |
| Drive: | pneumatic |
| Inlet thread size: | G 1/4" |
| Inner diameter: | 1 mm |
| Max. material inlet pressure: | 13 bar |
| Max. metering quantity: | 0.048 ml |
| Max. viscosity: | 5000 mPa.s |
| Metering frequency [Hz]: | 30 |
| Metering range: | 0.005 - 0.048 ml |
| Min. metering quantity: | .005 ml |
| Min. viscosity: | 10 mPa.s |
| Stroke detection: | Full / Empty |
| allowable maximum ambient temperature: | 40 Cel |
| allowable maximum material temperature: | 80 Cel |
